NAVIGASJON/navigation
PLOTTER (A): Simrad cx44 (apr2005, 2 slots c-map) NavStation SunView | Manual
Kart: C-MAP MAX NT-brikke (Baltikum)
PLOTTER (B): Simrad GO7 XSE (2017) | Manual
Kart: Navionics Baltikum på SD-brikke
INSTRUMENTER
WIND: SIMRAD Wind IS20 analog (pidestall cockpit)
SPEED/DEPTH: SIMRAD COMBI (pidestall cockpit)
AUTOPILOT: SIMRAD AP16 Control Unit, (nov2005) P/N Conde S/N 22087399DA6651 (pidestall in cockpit)
GIVERE/TRANSPONDERS
LOG (analog): AIRMAR Speed/Temp sensor 20-399-01, ST800-P120-HS
DEPTH: AIRMAR depth/echo (x2): 50 hz/200 hz
WIND: B&G 608 wind sensor (recommended upgrade from IS20 wind transponder (New 2021)
….
KOMPASS/compass
Fluxgate RC36 Rate Compass SN22086920AA10771
….
RADAR
Simrad DX45 4kW (for manual see Simrad cx44 Nav Station) manual
…
AUTOPILOT
Simrad AC10 Autopilot computer (NMEA0183) Computer P/N CODE S/N 22088108DA5875
AP16 kontrollenhet/control unit
RF 300 Rorgiver/rudder angle indicator
…
VHF
Simrad RS80B Marine VHF Radio Transceiver Processor, w/hand set Simrad RS82 (AHS82) SN: XE 01 10800
…
RADIO Pioneer FM/CD
TV Grundig, med rundtstrålende/360degree antenna
DATA/NETTVERK
NMEA2000 (navstation/Orca Core/wind/depth
NMEA0183/Simnet Manual
Cable hub/Koblingsboks (port cupboard saloon) Simrad 7618
ØVRIG/more
Instrumentpanel båtens elektronikk 12V
Plansje/wire map: Anschlussplan Panel 330 artnr: E08 012 330/HAN
Instrumentpanel sterkstrøm/onshore 220 cabling
